2.54mm (.100″) FFC/FPC Connector
Specification
| Measurement | 2.54mm (.100") |
| Circuits | 8~20 circuits |
| Current Rating | 1A AC DC |
| Voltage Rating | 200V AC DC |
| Temperature rating: | -25℃~+105℃ |
| Contact resistance | 20mΩ max. |
| Insulation resistance | 1000MΩ min. |
| Withstanding voltage | 500V AC/min. |
Standards
Product Details
- 2636 Series 2.54mm(.100")ZIF Top Entry FFC/FPC Connector
- 2636 Series 2.54mm(.100")ZIF Side Entry FFC/FPC Connector
| Product | 2636S |
| Circuits | 8~20 circuits |
| Material | Thermoplatic UL94V-0/Phosphor Bronze |
| Material Options | - |
| Color Options | - |
| Formula | P/N 2636S**V00* |
| Options | - |
| Other Informaton | - |
| Product | 2636S |
| Circuits | 8~20 circuits |
| Material | Thermoplatic UL94V-0/Phosphor Bronze |
| Material Options | - |
| Color Options | - |
| Formula | P/N 2636S**H00* |
| Options | - |
| Other Informaton | - |
